Accurate Existing-Condition Site Plans
US As Built creates detailed as-built site plans documenting the existing conditions of residential and commercial properties. Using high-accuracy 3D capture technology, we record buildings, hardscape, parking areas, landscape features and other visible site elements and translate that field data into clear, dimensionally accurate CAD drawings.
Our site plans provide architects, designers, contractors and property owners with reliable documentation for renovation, planning, permitting and construction.
Every project is tailored to the level of detail and drawing requirements of the property.
Detailed Documentation of Existing Site Conditions
Depending on project requirements, an as-built site plan can document:
Buildings & Structures
Building footprints, exterior walls, canopies, accessory structures and other improvements.
Parking & Vehicular Areas
Parking spaces, driveways, access lanes, loading areas, pavement edges and related features.
Walkways & Hardscape
Sidewalks, patios, plazas, steps, curbs, retaining walls and other constructed site elements.
Landscape Features
Planting areas, landscape boundaries, trees and other significant visible landscape features.
Fences, Gates & Site Features
Fences, gates, signs, bollards, equipment, lighting and other visible property features.
Site Relationships & Dimensions
Accurate locations and dimensional relationships between buildings, improvements and documented site elements.
Site Plans for a Range of Properties
Residential Properties
Document homes, garages, patios, driveways, walkways, landscape features, fences and other existing improvements for additions, remodels and property planning.
Commercial Properties
Capture buildings, parking areas, pedestrian routes, loading areas, site improvements and exterior property features for renovation, facilities planning and redevelopment.
Landscape & Exterior Improvements
Document hardscape, planting areas, site structures and other existing features to give landscape architects and designers a reliable base drawing for new work.
From Field Capture to Finished Site Plan
Capture Existing Conditions
We document the property using the appropriate combination of 3D laser scanning, Matterport capture and field measurement.
Build the Existing-Condition Record
Captured data is processed and reviewed to establish the locations and relationships of the required site elements.
Create the Site Plan
Our drafting team converts the measured conditions into a clear, dimensionally accurate plan based on the project scope.
Deliver the Required Files
Drawings can be prepared in the formats required by the project team, including CAD and PDF documentation.
Advanced 3D Capture Technology
Matterport + Leica BLK360 LiDAR
US As Built uses both Matterport and Leica BLK360 LiDAR scanning technology, allowing us to select the right capture method for the needs of each project.
Some projects benefit from using both technologies, combining precision dimensional capture with comprehensive visual documentation.
Leica BLK360 LiDAR Scanning
The BLK360 captures highly detailed three-dimensional point-cloud data along with spherical HDR imagery. It is particularly valuable when dimensional accuracy and detailed existing-condition documentation are critical to the project.
Leica specifies the current BLK360 at 4 mm accuracy at distances up to 10 meters, and its LiDAR system captures up to 680,000 points per second.
Matterport 3D Capture
Matterport creates an immersive digital representation of a property that can be viewed and navigated remotely. It is particularly useful for visual documentation, project collaboration and giving architects, designers, contractors and property owners continued access to a captured space after the site visit.
Matterport models can function as shareable digital twins, giving project stakeholders remote access to the documented space.
